Runva Winch – EWP3500A 12V
Features:
- Full steel gear reducer
- Runva patent cam cluth
- Self-lock braking action
- High current switch control directly
- Wireless remote control available
Specifications:
| Rated line pull | 3500 lbs (1588 kg) | ||
| Motor: permanent magnet | 12V:Input: 2.4 kW / 3.2hp; Output: 1.0 kW / 1.3hp 24V:Input: 2.9 kW / 3.9hp; Output: 1.2 kW / 1.6hp |
||
| Gear reduction ratio | 170:1 | ||
| Cable (Dia.× L) | Ø7/32″×42′ (Ø 5.4mm×12.8m) | ||
| Drum size (Dia.× L) | Ø1.46″×3.15″ (Ø 37mm×80 mm) | ||
| Mounting bolt pattern | 3.13″ (79.5 mm) 2-M8 | ||
| Line Speed Amperes Volts First Layer | Line Pull and Rope Capacity in Layer Line Pull | ||||||
| Line Pull Ibs.(kg) | Line Speed ft/min(m/min) | Current A | Layer of cable | Rated line pull lbs. (kg) | Total rope on the drun ft(m) | ||
| 12DC | 24DC | 12DC | 24DC | 1 | 3500(1588) | 5.9(1.8) | |
| 0 | 10.5(3.2) | 10.5(3.2) | 20 | 16 | 2 | 2789(1265) | 13.5(4.1) |
| 1000(454) | 8.9(2.7) | 9.5(2.9) | 75 | 40 | 3 | 2319(1052) | 22.0(6.7) |
| 2000(907) | 7.5(2.3) | 8.9(2.7) | 130 | 75 | 4 | 1984 (900) | 31.2(9.5) |
| 3500(1588) | 4.6(1.4) | 7.5(2.3) | 200 | 120 | 5 | 1733 (786) | 42.0(12.8) |
| Item | EWP3500A | ||
| Overall dimensions | 13.2″×4.6″×4.4″ | ||
| (L×W×H) | 335mm ×116mm ×112 mm | ||
| Net weight (Ibs/kg) | 22.0lbs / 10.0kg |
